ELECTRIC MONORAIL HOIST
S.K. Engineering is noted as one of the well known manufacturers, exporters and suppliers of Monorail Hoist. We have well equipped manufacturing unit, where we manufacture these hoists using high-end quality stainless steels & cast irons. We can customize our range as per specification provided by our clients. Our entire product line finds huge application in construction, mining and engineering industries for loading and unloading purpose. High load carrying capacity, robust construction and easy maintenance are the distinguished features of our Monorail Hoist.
Product Specifications:
|
Motor |
0.5 HP, 3 Phase, 1440 RPM, Class F, 40% Intermittent Duty, Induction Motor |
|
Exceptions to EH2 Hoist |
6.3 mm, Grade 80, Alloy Steel Material Load Chain |
|
Overall Dimensions |
560 x 410 x 265 mm (Head room x Other Dimensions) |
|
Headroom (With Monorail Electric Traveling Trolley |
620 mm |
|
Headroom (With Monorail Geared Traveling Trolley) |
600 mm |
|
Weight of Hoist at 3 Mtr. Lift |
35 Kgs |
|
No. of Falls of Load Chain |
1 Falls |
|
Headroom (Hook Suspension) |
560 mm |
|
Extra Weight per Meter |
1.2 Kgs. |
|
Hoisting Speed |
6.4 Mtr./ Min |
From our gallery
Service Feature Highlights
- Customization Options
- Installation Services
- Routine Maintenance
- Emergency Repairs
- Global Support
- Operator Training
- Spare Parts Supply
Some FAQ About This Product
An Electric Monorail Hoist is a lifting device that travels along a fixed, single-track rail system, powered by electricity. It combines the functionality of a monorail with an electric hoist for lifting and transporting heavy loads efficiently in industrial environments.
The Electric Monorail Hoist is designed for handling medium to heavy loads, typically ranging from 500 kg to 10 tons depending on the hoist's design and model. It is ideal for industrial applications that require repetitive lifting and transport of goods.
The hoist operates by running along a single-track rail powered by an electric motor. The motor drives the hoist, allowing it to move loads along the track, lifting and lowering them as needed. It can be operated using manual pendant control or wireless remote control.
Yes, the Electric Monorail Hoist can be customized in terms of lifting height, load capacity, track length, and speed control to meet specific operational needs. Customization ensures that the hoist system works efficiently within your existing setup.
The typical lifting speed of the Electric Monorail Hoist ranges from 3 m/min to 10 m/min, depending on the model. The movement speed can be adjusted to fit the specific needs of your application.
